-Characteristics and advantages-
Widely applicable scenarios
Suitable for aquaculture, landscape fish ponds, aquarium engineering, etc., both freshwater and seawater can be used.
Automatic liquid level detection
The automatic liquid level detection device automatically controls the operation of the microfilter.
Long service life
The main body is made of 304 or 316L with high corrosion resistance.
Automatic flushing of filter screen
Automatically clean the filter screen according to the settings.
Unique tilt angle design
The grid adopts an inclined design, which is conducive to the collection of pollutants in water.
Filter screen heat setting
The filter screen is not easily deformed after heat setting treatment
Note: Other sizes can be customized
Model | 100T | 150T | 200T | 300T | 400T | 500T |
External dimensions (length, width, height) | 125*120*142cm | 150*120*142cm | 202*120*142cm | 230*135*159cm | 280*164*191cm | 305*190*215cm |
box | 304 stainless steel | 304 stainless steel | 304 stainless steel | 304 stainless steel | 304 stainless steel | 304 stainless steel |
Drum and filter material | Detachable nylon filter screen | Detachable nylon filter screen | Detachable nylon filter screen | Detachable nylon filter screen | Detachable nylon filter screen | Detachable nylon filter screen |
Filtration | 200 mesh | 200 mesh | 200 mesh | 200 mesh | 200 mesh | 200 mesh |
Drive motor | 380V 550W | 380V 550W | 380V 550W | 380V 550W | 380V 750W | 380V 1100W |
Backwash pump | 304 stainless steel 380V 1100W | 304 stainless steel 380V 1100W | 304 stainless steel 380V 1100W | 304 stainless steel 380V 1100W | 304 stainless steel 380V 1850W | 304 stainless steel 380V 2200W |
Discharge outlet | 75mm | 75mm | 75mm | 75mm | 75mm | 75mm |
Weight | 185kg | 220kg | 270kg | 460kg | 630kg | 850kg |
*Please refer to the actual factory products for specifications and parameters. The above content is for reference only
